EASYSOLDER END
- Waterproof Solder Connector
- Connect flexible or solid wires in one single step.
- Solders, insulates, connects, and seals against water and dust.
- The 3 lead-free solder rings ensure a saturated solder joint!!
- Extreme temperature resistance from -60°C to +125°C allows for maximum application possibilities!
- Transparent insulation allows visual inspection.
- No voltage loss.
- Permanently flexible.
| Textual description |
Waterproof Solder End Connector Professional solder end connector for reliably sealing cables with a waterproof, corrosion-resistant seal. When heated, the solder ring melts and the sleeve shrinks, creating a strong electrical connection and a perfect seal. Features:
Available sizes:
With the waterproof end solder connector, you achieve a professional, safe, and durable cable termination – ideal for vehicles, machinery, and outdoor installations.
|
| Use |
Easysolder End is designed to connect multiple wires and safely insulate endpoints. Suitable for both repairs and newly installed components. Ideal for applications requiring low resistance. Also suitable for outdoor wiring. Perfect for truck and bus manufacturers, contractors, farmers, excavation companies, electrical and industrial maintenance services, shipbuilding and repair, towbar installation, alarm systems, garages and body shops, etc. 3 solder rings! (Green version has 2 rings) Quick installation. Connects, solders, insulates, and seals — all in one operation. To be heated using a gas torch (Flamewarp). |
| Instructions for use |
Choose the correct diameter. Strip approximately 6 mm of the cable. Slide the EASYSOLDER over the cable and, if necessary, degrease the cable sheath with MEC-ELEC CLEAN. Heat the solder until it activates. Then work toward the outer ends. |
| Dielectric strength | 25 MV/m |
| Breakdown voltage | 600V |
| Volume resistivity | 1×10^17 Ω⋅m |
| Voltage drop | 2 mV |
| IP value | 6 - 7 |
| Shrink temperature |
+300°C |
| Temperature range | -60°C to +125°C |
| Outer layer | Radiation cross-linked transparent polyolefin |
| Solder ring | Sn 42%, Bi 58% ROM 1 flux |
| Sealing ball | Colored glass |
| Copper spiral | Drawn from square copper wire. This increases the mechanical strength. |
| Sealing gasket | High-quality hot melt adhesive |
| Andere info |
Environment & Safety ROHS approved |
